UNI-T UTG9354T 350MHz 4Ch Elite-Series Arbitrary Waveform Generator
UNI-T UTG9354T 350MHz 4Ch Elite-Series Arbitrary Waveform Generator thumbnail

EAN 6935750593554

EDIT PRODUCT

UNI-T UTG9354T 350MHz 4Ch Elite-Series Arbitrary Waveform Generator

(Write a Review)
Barcode Formats: EAN-13 6935750593554
Category: Tools > Measuring Tools & Sensors > Electrical Testing Tools
Manufacturer: UNI-T
Description:   Transform your testing encounters with the UNI-T UTG9354T Waveform GeneratorUNI-T UTG9354T Arbitrary Wave Featuring an array of advanced functionalities the UNI-T UTG9354T Elite-Series Arbitrary Waveform Generator is your gateway to precision versatility and unparalleled performance. Step up your testing capabilities with the UTG9354T waveform generator a genuine game-changer for your engineering pursuits. UNI-T UTG9354T Key Specifications: Maximum Frequency: 350MHz Channel: 4 Arbitrary Wavelength: 64Mpts Maximum Sampling Rate: 2.5GSa/s Vertical Resolution: 16bits Minimum Edge Time: within 1.5ns adjustable duty ratio Maximum Output Swing: 20Vpp Digital Protocol Output: SPI I2C UART Screen Display: 10.1-inch capacitive touch screen 1280*800 resolution UNI-T UTG9354T Top Features: Direct Digital Synthesis (DDS) Function: This device incorporates the Direct Digital Synthesis (DDS) function providing a high-precision stable pure and low-distortion signal. Additionally it excels in generating high-frequency waves with rapid rising and falling edges. As a high-performance multifunction four-channel arbitrary function generator it boasts a user-friendly touch screen superior technical specifications and a graph display designed for enhanced work performance. This versatile product is designed to meet both current and future testing requirements offering a multitude of capabilities to support various applications.UNI-T UTG9000T Frequency Meter Digital Protocol Output: Equipped with three standard serial protocols–SPI I2C and UART–UTG9354T allows users to compile corresponding parameters and generate serial signal waveforms for each protocol. This functionality serves to test and verify protocol interfaces providing input signals for interface assessment. This feature enhances the specificity and effectiveness of interface measurements during operations. Frequency Meter: Incorporated within is a built-in frequency meter simplifying the process of testing frequency signals. To perform the test connect the signal to the counter on the rear panel and the result will be readily obtained. Channel Merging: UTG9354T offers the capability to combine CH1 with CH2 and CH3 with CH4 providing exceptional real-time and true superposition features to display complex waveforms effectively. Four-Channel Sync Display: This model comprises four channels with CH1 and CH2 designated as the primary channels while CH3 and CH4 belong to the secondary channels. Users have the flexibility to switch and view signal parameters for all four channels simultaneously on a single screen simplifying operation and facilitating the recording of parameters.UNI-T UTG9000T Channel Merging Multiple Modulation Mode: It provides support for various analog and digital modulation techniques including AM FM PM DSBAM QAM ASK FSK 3FSK 4FSK PSK BPSK QPSK OSK PWM and SUM. The device offers both internal and external modulating signal sources offering a diverse range of modulation signals to cater to waveform generation requirements spanning radio TV and mobile networks. Channel Coupling: CH1 couples with CH2 and CH3 couples with CH4 through a channel coupling function. Activate this function when another channel requires the same or related signal waveform. UTG9354T offers three coupling modes t.
Attributes:
  • MPN: UTG9354T
Product Reviews WRITE A REVIEW

No reviews posted yet.

Online Stores
ADD STORE

Sponsored affiliate online retailers for EAN 6935750593554:

  1. Walmart: $3,779.00
  2. Global Test Supply: $3,779.00
